Allen & Heath CQ-20B Ultra-Compact Digital Mixer

CQ-20B Ultra-Compact Digital Mixer with Wi-Fi 20in / 8out

Designed for life on the stage, CQ-20B is the highest channel-count mixer in the range and is controlled via the free CQ MixPad app.

Although the CQ-20B is designed for life on the stage, you’re free to mix from anywhere in the venue via the free CQ MixPad app and the integrated dual-band Wi-Fi. CQ MixPad gives you control over all parameters of the mixer so you can soundcheck, mix and record from your mobile device or computer.

The CQ-20B is designed to be controlled via the intuitive CQ MixPad app and features powerful integrated dual-band Wi-Fi so you don’t need to connect an access point or router to use apps for control of the mixer. Just connect your devices to the CQ’s secure Wi-Fi network and you’re ready to go.

Features

• 20x Inputs to Mix

• (16x Mono/Linkable, 4x Stereo)

• Stereo MainLR Output

• 6x Aux Outputs

• (Linkable up to 3x Stereo)

• 8x XLR Mic/Line Input Sockets

• 8x XLR/Jack ‘Combi’ Mic/Line Input Sockets

• (2 with Hi-Z option)

• 2x Stereo Line Input Sockets

• (each 2x TRS)

• 8x XLR Output Sockets

• 2x TRS Alt Out Sockets

• Stereo Headphone Output

• Dedicated Stereo USB Input to Mix

• Dedicated Stereo Bluetooth Input to Mix

• 96kHz Input/Output Processing

• 4x Multi-FX Engines

• Built-In Dual Band WiFi (CQ as Host)

• RJ45 Network Socket (CQ as Client)

• USB-A For Stereo Audio Record/Playback and Data

• USB-B For Multichannel Audio Record/Playback (24x24)

• SD Card Slot for Multichannel Audio Record/Playback (24x24)

• Configurable Single/Dual Footswitch Connection

• Configurable Chromatic Channel Meter LED

• Rack Mountable (Optional Kit Available)

• IEC Mains Connection with Worldwide PSU

• Control Via Free Apps – Windows/MacOS/iOS/Android
