Ecler SAMI-612 Preamplifier

SAMI-612 is an installation audio mixer in standard rack format, featuring 6 MIC/LINE Stereo inputs, 1 Stereo MIX input and 1 Stereo MAIN output + 1 Stereo REC output. Each input has a dedicated 3-band tone control, a feature which is fundamental to get a perfect microphone mix in an installation. Input 1 includes talkover (priority) function over the mix bus and additional front panel jack connector. Main output ST/MONO mode switch and MUTE port for external dry contact triggering.

FEATURES

• 6 input channels, 2 main outputs 19” installation mixer

• Micro sensitivity level can be adjusted on the back panel

• +18V Phantom Power available in all “MIC” inputs

• Direct micro input on front panel, channel 1

• Includes a talkover assigned to “INPUT 1” with internal release time adjustment

• Three-band tone controls for each channel, accessible with a screwdriver

• Vu-meter for the mix signal

• Two internally adjustable output levels

• Recording output

• Direct access to the mixing bus allowing you to connect another mixer and increase the number of inputs

• MUTE remote control input enabled by external dry contact closure for connecting fire detection systems and other safety devices.

• Mono/stereo switch
